NUIE Square Thermostatic Bar Valve & Kit

£323.52

Shipping calculated at checkout.

The perfect solution to multi-option showering. Thermostatically controlled. Square shower head. Square handset. Thermostatic control to +/- 2 degrees even if the water pressure fluctuates. Full thermal protection to prevent scalding in the event of hot or cold water shut off. In the event of hot or cold water failure the valve will shut down as per the relevant standard. Suitable for high pressure water systems. Suitable for unvented mains pressure systems. Suitable for shower pumps. Manufactured from high quality brass & ABS.

Colour Finish: Brushed Bronze

Flow Rate At 0 5 Bar L Min: 3.0000

Flow Rate At 1 Bar L Min: 5.0000

Flow Rate At 2 Bar L Min: 9.0000

Flow Rate At 3 Bar L Min: 12.0000

Guarantee: 3 Years

Handle Type: Square

Material: ABS,Brass

Minimum Operating Pressure Bar: 1 Bar

Mount Type: Surface/Wall

Packaging Height: 85.0000 mm

Packaging Length: 845.0000 mm

Packaging Width: 405.0000 mm

Pipe Centres Mm: 150 MM

Product Depth: 465 mm

Product Height: 1200 mm

Product Width: 200 mm

Tmv2 Approved: No

Tmv3 Approved: No

Valve Cartridge Type: 1/4 Turn

Wras Approved: No
